HDMI 4X4 Matrix Switcher and DA over 2 UTP for rent rental

Description:

Offers Unprecedented Flexibility and Convenience by Extending High Definition Audio/Video Signals from any of 4 HDMI Sources to any of 4 Remote Displays over

Two Cat5e/Cat6 Cables

Transmission Range: Extends 1080p resolutions up to 100 ft over Cat5e Cables; Extends 1080p resolutions up to 110 ft over Cat6 Cables

Super IR & RS232 control system, IR transport channel can be forward or backward. IR transmitters and receivers are needed (Part #s 280720, 280721)

Supports IR control in the 38 KHz mode

Locking HDMI Compatible

19" Rack Mounting

9V DC, UL Listed Power Supply for 4 x 4 Matrix Unit

4x4 Matrix Dimensions: 17. 5"W x 1.875"H x 3.25"D

Receiver Dimensions (4 Total): 1.75"W x .875"H x 8.25"D

Includes IR Remote Control

High Speed Chip Set that Supports 3D and 4K x 2K

Full HD1080P/120HZ

HDCP Compliant

Supports Digital Audio Format, DTS-HD/Dolby-True HD/LPCM7.1/AC3/DTS/DSD

Unique Circuit Design Allows for Protection against High Voltage and Peak Currents

Tested for Compatibility with all leading HD Video brands

Tested with 7.1 Home Theater Systems

Features:

  • Enables up to 4 HDMI video/audio devices to be independently switched to 4 HDMI displays or projectors for uncompressed digital distribution up to 40m (130ft) over a single Cat5e/Cat6 cable
  • Additional HDMI output per UTP output for flexibility or mi
  • Designed work seamlessly together for complete compatibility and full management of handshakes, screen resolutions and HD signal distribution to each display point, whether in a residential or commercial environment
  • Fully cascadable so multiple unit
  • Conforms to IEEE-568B standards
  • Each HDMI port also supports DVI signals
  • 2k resolution supported
  • Fully 3D compatible

Options:

  • With UTP
  • Without UTP as switcher or DA
